Principle and Structure Characteristics of Bucket Elevator
Date:2016-09-27 Source:zk corp Views:
ZK bucket elevator contains: TH round link bucket elevator, NE plate chain bucket elevator, TG steel core belt bucket type lifting machine, dehydration bucket type vertical vibration hoist machine, lifting etc..
Characteristics of TH round link bucket elevator
1 It adapt the assembly sprocket, we can unscrew the bolts, remove the flange when the sprocket wear is to a certain extent, the replacement is convenient, which can also save material, reduce maintenance costs.
2 The hammer lever tensioning device is used in lower part, it can realize automatic tensioning. It is not required to adjust after installation, which can maintain a constant tension force, thereby ensuring the normal operation of the machine and avoiding slipping.
3 The traction part is a low alloy high strength circular chain. it has high tensile strength and wear resistance, long service life.
Features of NE plate chain bucket elevator:
1 Good sealing, simple structure.
2 Convenient operation and maintenance, less vulnerable parts.
3 High lifting height, stable and reliable operation, low noise, easy maintenance.
4 Large transport capacity, the series of hoist with NE15 ~ NE800 a variety of specifications. Lifting range is 15 ~ 800m3/h.
5 Material flow into the hopper and get the top by the chain, material self unload under the action of gravity.
NE plate chain bucket elevator main structure
1 It is composed of the operation components, drive device, the upper device, the middle of the housing, the lower part of the device.
2 Run parts: composed by the hopper and special plate chain, NE30 use single row chain, double chain is used in NE50--NE800.
3 The driving device: use a variety of driver combination, (according to the actual needs of users). The driving platform is provided with a service frame and a rail,which is divided into left and right two.
4 The upper device installation track (double chain), backstop, with anti export is expected to rubber plate.
5 Middle section: part of the middle section has track (double chain) to prevent the work of the chain swing.
6 The lower part of the device: the installate automatic tensioning device.
Causes and measures of abnormal sound during operation of bucket elevator
1 The guide plate and the bucket collide, we should adjust guide plate position.
2 Bucket elevator and base plate chain bucket collide, we should adjust the elastic device..
3 The drive shaft and the driven shaft key relaxation, sprocket displacement, chain bucket and shell collision, we should adjust the sprocket position.
4 Block or other foreign bodies in a lock shell, we should stop and remove foreign body.
5The guide plate and the bucket are clamped between the material base material, we need to enlarge investment angle.
6 Sprocket (drive, driven sprocket) is not correct, we need update the sprocket teeth or replace the sprocket.
7 Bearing failure or it can not be flexible operation, the bearing should be replaced.
