Shaftless Screw Conveyor

Date:2016-07-24 Source:zk corp Views:

Screw conveyor is a kind of transport equipment mainly used for conveying powder, granular and small pieces of material and widely used in chemical industry, building materials and food. Conveying different kinds of materials requires different types of screw conveyor and screw conveyor prices are also different on the basis of models and t uses. Manufacturers need to choose cheaper and high efficiency of the screw conveyor according to different situations. Shaftless screw conveyor has been widely used with the development of environmental protection and new energy. The characteristics of anti - winding, clogging and viscosity of shaftless screw conveyor are widely recognized and the technology is becoming more and more perfect.
According to the different components, the screw conveyor can be divided into shaft spiral and shaftless spiral. A helical blade of a shaft screw conveyor is arranged on the spiral shaft and the rotation of the spiral blade is driven by the rotation of the screw shaft, the material is transported through the operation of the material. The shaftless screw conveyor, relative to the shaft screw machine, which adopts whole spiral blade instead of spiral blade in spiral casing. Material is pushed through the blade, so that the non axis spiral conveyor has a strong anti winding. The shaftless spiral conveyor has a strong anti winding because t no spiral shaft. Shaftless screw conveyor mainly consists of driving device, head assembly, chassis, shaftless screw body, tank lining plate, feed port, a discharge port, a machine cover (when needed). At present, the shaftless screw conveyor is mainly used in the waste treatment industry and biomass power generation industry.
The shaftless scew converyor is popular in the waste treatment industry. The conveyor with enhanced third generation has large transmission torque and spiral blade is not easy to deform, the whole machine is sealed. It can directly connect with the power generating boiler. The effect of the lock is good and has less heat loss. More than 40 garbage power generation enterprise proved that using shaftless screw conveyor as the furnace feeding equipment can increase the capacity by 20% at least compared with the original 200 t per day.
The shaftless scew converyor is also widely used in biomass power generation industry. A shaft screw conveyor are easy to be enwinded by biomass to need manual cleaning. Also conveyor can not work properly resulting in that the boiler can not be stable combustion, which thereby affects the efficiency of power generation. Shaftless screw conveyor overcomed all the problem above. In addition, shaft scew body also has the effect to tear biomass, which makes the furnace before feeding be stable. So the biomass can fully burnt, and the power generation efficiency will be improved.
Shaftless scew converyor has many advantadges, but it does not mean it is better than the shaft converyor, we need choose the suitable product according to our need, such as screw conveyor price, type and the material we need to delivery. You can contact us if you want to know anything about scew converyor.
