WGM-30 horizontal dry-type ball mill

Date:2016-12-14 Source:zk corp Views:


Equipment performance
First, the dry-type ball mill technical parameters:
1. The total volume of ball mill barrel 30L, material handling capacity: 15L.
2. The motor power 1.5kw, speed 0-68r / min, frequency control.
3. The ball set the digital time 0-999 minutes, regular shutdown.
4. Power supply: 380V / 220V / 50Hz.

Second, the main components of technical notes
1.The motor is Y series three-phase asynchronous motor, voltage 380V, rated output power 1.5kw, and use Anhui "Wannan" motor, inverter uses in Shenzhen, "Tai Yuen."
2. The total volume of barrel 30L barrel, barrel uses 8mmSUS304 stainless steel wear-resistant steel plate production, the barrel at both ends of the rolling bearing fixed to the rack, turning flexible.
3.The frame material by the steel, the overall frame with A3 steel plate coating, the rack surface proceed anti-rust treatment, the surface adopt paint. The overall frame is smooth and flatness inside and outside.

4. Ball mill and reducer uses chain drive, cycloid reducer cycloid reducer, motor and reducer adopt direct connection.
5. The inlet and outlet diameter is 200 mm, when the ball mill, the cover will be sealed barrel mouth; discharge, the use of mesh fence, the ball mill material in the barrel block, discharge materials. Closed out the material, no dust pollution, clean plant.
6. The equipment for the closed structure, the material without dust pollution, sealed enclosures with 3mmSUS304 stainless steel production.
7. Barrel speed of 0-68r / min, frequency control, noise is less than 65db.
8. The ball mill dynamic balance is good, no impact. Equipment running smoothly, no obvious vibration.
9. Milling time digital settings (0-999 minutes), regular shutdown.
10 .All electrical appliances use high-quality brand-name products, equipment control for the random control.

The third part: after - sales service commitment
1. The overall design of the whole people-oriented, easy to operate and maintenance.
2. Equipment production process in strict accordance with the relevant national standards of manufacture, all ordinary steel use in the national standard high-quality steel, stainless steel adopt SUS304 stainless steel.
3. All of the machinery have improved after-sales service, products carry out "Three Guarantees". Warranty period is one year, life-long maintenance warranty.
4. Electrical main components and components are made up of high quality brand-name products, the electrical components is good quality, sensitive and reliable.
5. As a result of supply-side causes equipment failure, the supplier unconditionally free maintenance; due to demand-side cause equipment failure, maintenance fees and materials charge fees.
6. The demand side needs service, the supplier within 24 hours to reach, depending on the distance.
