Introduction

MBS type rod mill grinding media are steel rod, mainly for ore processing, suitable for non-ferrous metal and non-metallic mineral resources, compared to the general grinding equipment, the most notable feature is the steel rod in the interior of MBS type rod mill contact the material was linear, this can ensure that the equipment has a certain selective grinding effect, through MBS type rod mill grinding materials have more uniform particle size, will not appear over powder phenomenon in the process of grinding, improve the overall application value of the finished material.

Application Of Rod Mill:

Rod mill is widely applied in metal and nonmetal mine, water conservancy, glass and construction materials industries, mainly suitable for grinding various ores and rocks and artificial sand-making. Our high-efficiency rod mill adopts rolling bearing support instead of sliding bearing support with bearing bush. Therefore, it has advantages of even discharging size and high capacity.

Features

1. The discharging granularity of rod mill is evener and the output is higher.

2. The grinding media contact with the ore in a linear manner, so that it has selective grinding function.

3. When used for coarse grinding, the processing amount of rod mill is higher than that of the ball mill with the same specification.

Technical Parameter

Model	Cylinder Diameter (mm)	Cylinder Length (mm)	Motor Model	Motor Power (kW)	Motor Rotating Speed (r/min)	Length (mm)	Width (mm)	Height (mm)	Capacity (t/h)	Effective Volume (m³)	Weight (kg)
MBY 0918	900	1800	Y225M-8	22	730	4980	2370	2020	0.62~3.2	0.9	5700
MBY 0924	900	2400	Y250M-8	30	730	5670	3280	2020	0.81~4.3	1.2	5880
MBY 1224	1200	2400	Y280M-8	45	730	6450	2800	2500	0.4~4.9	2.28	12308
MBYg 1530	1500	3000	JR117-8	80	725	7253	3070	2280	2.4~7.5	5	21210
MBYg 2130	2100	3000	JR136-8	180	735	8122	4220	3073	14~35	9	42123.5
MBYg 2136	2100	3600	JR137-8	210	735	8958	4320	3025	43~61	10.8	45800.5
MBYg 2736	2700	3600	JR158-8	380	743	10764	5750	3620	32~86	17.7	90441
MBY 2740	2700	4000	TDMK400-32	400	187.5	12300	5700	4700	43~110	20.4	75000
MBY 3040	3000	4000	JR1510-8	570	740	9800	3900	3900	54~135	26	90000
MBY 3245	3200	4500	TDMK800-36	800	167	14600	7000	5300	64~180	31	113000
MBY 3645	3600	4500	TDMK1250-40	1250	150	15200	8800	6800	80~230	41.8	139000
MBY 3654	3600	5400	TDMK1600-40	1600	150	15900	8800	6800	100~250	49.7	150000
