Introduction

ZK Linear vibrating screen has a unique effect on powdery, granular materials selection and classification. It uses a vibrating motor to throw materials in an upward and forward linear motion. These models typically operate with twin-vibrating motors that function in a synchronized fashion and move the centrifugal force parallel to the motor access. Centrifugal and gravity force help throw the material in the direction it moves, which effectively reduces its size and grades it.

Linear vibrating screens are available in single or double deck types with sizes up to four meters wide and nine meters long. They’re known for being rugged, stable and simple to maintain. Typical applications include primary and secondary classification, sizing, de-sliming, washing, dewatering and hot-material screening, among others.

Application: aluminum powder, lead powder, copper powder, ore alloy powder, powder electrodes, manganese dioxide, copper powder, magnetic power, abrasives, refractory, kaolin, limestone, alumina, heavy carbon acid calcium, quartz sand.

Features

1. Advanced design, ingenious and easy to assemble, easy operation, high efficiency of processing capacity.

2. Unique screen structure design, convenient and fast change screen (only 3 to 5 minutes), in addition, this design allows the use of a variety of screen (nylon, special dragon, PP nets).

3. The parent network to fully support the fine mesh, so fine mesh scored a longer life, and reduce the supplies of fine mesh, the production process and the long time can reduce a lot of cost.

Technical Parameter

Model	Screen Area (㎡)	Screen Inclination Angle(°)	Feed Particle Size (mm)	Motor Power (kW)	Capacity (t/h)	Weight (t)
ZK1022	2.25	-5~5	<250	3x2	4.5-90	2.2
ZK1230	3.6	-5~5	<250	4x2	7.2-144	2.6
ZK1237	4.5	-5~5	<250	5.5x2	9-180	3.1
ZK1437	5.25	-5~5	<250	5.5x2	12-250	3.2
ZK1445	6.3	-5~5	<250	7.5x2	12.6-252	4.1
ZK1637	6	-5~5	<250	5.5x2	12-240	3.5
ZK1645	7.32	-5~5	<250	11x2	95-280	4.5
ZK1837	6.75	-5~5	<250	11x2	90-270	5
ZK1845	8.1	-5~5	<250	11x2	16.2-234	5.5
ZK1852	9.45	-5~5	<250	11x2	18.9-378	5.9
ZK2045	9	-5~5	<250	11x2	16.2-324	6
ZK2052	10.5	-5~5	<250	11x2	21-420	6.4
ZK2060	12	-5~5	<250	15x2	24-480	7.6
ZK2445	10.8	-5~5	<250	15x2	21.6-432	7.4
ZK2452	12.6	-5~5	<250	15x2	25.2-504	8.2
ZK2460	14.4	-5~5	<250	15x2	28.8-576	9.2
ZK3045	13.5	-10	<250	15x2	27-540	10
ZK3052	15.75	-5~5	<250	22x2	31.4-628	10
ZK3060	18	-5~5	<250	22x2	17.5-525	11
ZK3645	18	-5~5	<250	22x2	37.8-756	12.2
